Telemecanique Sensors
Telemecanique L1472M Rotary Actuated Limit Switches
Telemecanique Sensors
Telemecanique L1472M Rotary Actuated Limit Switches
SKU323609
MFGR #L1472M
Your Cost: $446.89/ea
Telemecanique Sensors L1472M CABLE SWITCH 600VAC 10A T-L,-10...185 deg.F,1 entry for 1/2 - 14 NPT conforming to ANSI B1.20.1,fixed,20 A,L100/300,fixed,limit switch,rotary head,L100-L300,L300-L100,rotary head,severe duty mill,fixed,neutral position
Telemecanique Sensors L1472M CABLE SWITCH 600VAC 10A T-L,-10...185 deg.F,1 entry for 1/2 - 14 NPT conforming to ANSI B1.20.1,fixed,20 A,L100/300,fixed,limit switch,rotary head,L100-L300,L300-L100,rotary head,severe duty mill,fixed,neutral position
Action Snap Actuator Spring return Catalog Number L1472M Contact Rating A600/P600 Country of Origin MX Currency USD Dimensions 4.95 in H x 2.25 in W x 3.41 in D Enclosure Type NEMA 1/2/4/12/13/IP67 Gross Weight Per Pack 1.5000 lb Gross Weight per Pack Metric 680.39 Gross Weight UOM Metric g Height 32.2580 in Item Group 22426 Length 81.9350 in Material Cast Aluminum Number Of Poles 2 Returnable N Series Severe Duty Mill Temperature Rating -10 to 185 °F Terminal Type Screw/Clamp Type Fixed Rotary Head UNSPSC 39122213 UPC 11 78590116985 UPC 12 785901169857 Width 12.7000 in Stock Status NONSTOCK Brand Telemecanique Sensors Manufacturer Telemecanique Sensors Amperage Rating 20 A Contact Configuration 1NO DPST-DB Voltage Rating 600 VAC FIXED,NEUTRAL POSITION 1 entry for 1/2-14 NPT conforming to ANSI B1.20.1 Neutral position 20 A at 120 VAC, 12.5 A at 240 VAC, 6.25 A at 480 VAC, 5 A at 600 VAC, 5 A at 120 VDC, 1 A at 250 VDC, 0.2 A at 600 VDC contact rating
content loaded
content loaded
content loaded
content loaded
- Attributes
- Documents & Resources
- Features
- Substitute Products
| Action | Snap |
| Actuator | Spring return |
| Catalog Number | L1472M |
| Contact Rating | A600/P600 |
| Country of Origin | MX |
| Currency | USD |
| Dimensions | 4.95 in H x 2.25 in W x 3.41 in D |
| Enclosure Type | NEMA 1/2/4/12/13/IP67 |
| Gross Weight Per Pack | 1.5000 lb |
| Gross Weight per Pack Metric | 680.39 |
| Gross Weight UOM Metric | g |
| Height | 32.2580 in |
| Item Group | 22426 |
| Length | 81.9350 in |
| Material | Cast Aluminum |
| Number Of Poles | 2 |
| Returnable | N |
| Series | Severe Duty Mill |
| Temperature Rating | -10 to 185 °F |
| Terminal Type | Screw/Clamp |
| Type | Fixed Rotary Head |
| UNSPSC | 39122213 |
| UPC 11 | 78590116985 |
| UPC 12 | 785901169857 |
| Width | 12.7000 in |
| Stock Status | NONSTOCK |
| Brand | Telemecanique Sensors |
| Manufacturer | Telemecanique Sensors |
| Amperage Rating | 20 A |
| Contact Configuration | 1NO DPST-DB |
| Voltage Rating | 600 VAC |
| FIXED,NEUTRAL POSITION |
| 1 entry for 1/2-14 NPT conforming to ANSI B1.20.1 |
| Neutral position |
| 20 A at 120 VAC, 12.5 A at 240 VAC, 6.25 A at 480 VAC, 5 A at 600 VAC, 5 A at 120 VDC, 1 A at 250 VDC, 0.2 A at 600 VDC contact rating |
